Technical specification
Version 1.0.4 - 2020-08-04 19Translation of original instruction
MT60 EN
MT60_GB_2.fm
2.3 Horizontal spindle
Spindle seat ISO 40 DIN 2080
Drive motor 2.2 kW
Throat [mm] 35 - 370
Speed 40 - 1300 rpm
Gear stages 9
2.4 Cross table
Table size [ mm ] 1270 x 280
max. load of cross table [ kg ] 150
T-slot size / distance / number 14mm / 50mm / 4
Table feed X axis drive 1.5 kW
X axis handwheel scale
4 mm/rev - graduation 0.02 mmY axis handwheel scale
Z axis handwheel scale
2.5 Travels
X axis automatic / manual [mm] 680 / 750
Y axis manual [mm] 230
Z axis manual [mm] 360
2.6 Dimensions
Installation plan on page 24
Total weight [kg] 1300
2.7 Work area
Keep a work area of at least one metre around the machine free for operation and maintenance.
2.8 Coolant equipment
Power of the cooling lubricant pump [ W ] 40 W
Capacity cooling lubricant tank [ L ] 12
Delivery height [ meter ] 3
2.9 Environmental conditions
Temperature 19 - 21 °C (for an optimum milling result)
permissible range + 10° to + 35°C
Admissible relative humidity 5...90 % no condensation
30% to 90% at 35°C
90 % at 21°C
Compressed air 700...1060 hPa
Environmental conditions - storage 5 - 45 °C
