Version 1.0.4 - 2020-08-0424 Translation of original instruction
MT60
EN
MT60_GB_3.fm
3.6 Set-up and assembly
3.6.1 Installation plan
3.6.2 Requirements regarding the installation site
Keep a work area of at least one metre around the machine free for operation and mainte-
nance.
In order to achieve sufficient safety against falls by slipping, the accessible area in the mechani-
cal machining zone of the machine must be equipped with a slip resistance. The slip-resistant
mat and/or slip-resistant flooring must be at least R11 in accordance with BGR 181. The deter-
mination of this requirement resulted in the risk assessment of the machine.
The used shoes must be suitable for being used in those machining areas. The accessible sur-
faces must be cleaned.
Organise the working area around the milling machine machine according to the local safety
regulations.
INFORMATION
In order to achieve high levels of functionality and machining accuracy, as well as a long
service life of the machine, the set-up location should meet certain criteria.
The following points should be noted:
220 ~ 550
60 ~ 420
0 ~ 360
974
1028
1280
2110
546
600
Center of gravity
