5.7.1 Entering the parameters
Parameter Description
1 - 1 CCE Coordinate plane of the circle: X-Y
2 - 1 CCE Coordinate plane of the circle: Y-Z
3 - 1 CCE Coordinate plane of the circle: X-Z
To select X-Y, Y-Z or X-Z as the coordinate plane, press the key.
To enter the midpoint of the circle on the coordinate plane, use the numeric keys and confirm with the
key.
Parameters Description
1 - 2 C_d Diameter of the circle or arc in the coordinate plane: X-Y
2 - 2 C_d Diameter of the circle or arc in the coordinate plane: Y-Z
3 - 2 C_d Diameter of the circle or arc in the coordinate plane: X-Z
To enter the diameter of the circle or arc, use the numeric keys and confirm with the key.
Parameters Description
1 - 3 .H Number of coordinate points: X-Y
2 - 3 .H Number of coordinate points: Y-Z
3 - 3 .H Number of coordinate points: X-Z
Input the number of coordinate points using the numeric keys
and confirm with the key.
Parameters Description
1 - 4 5_A Start angle: X-Y
2 - 4 5_A Start angle: Y-Z
3 - 4 5_A Start angle: X-Z
To enter the start angle on the coordinate plane, use the numeric keys
and confirm with the key.
