5.8 Inclined Plane
Creates an inclined plane in a coordinate system such that processes can be carried out on
said inclined plane.
The parameters are displayed in the Rotation Speed field.
The last entered value of each parameter is shown in the row of the X axis.
Entering a new value is specified in the row of the Y axis.
5.8.1 Entering the parameters
5.8.2 Positioning to a Coordinate Point on the Inclined Plane
The machine axes proceed until the positions of the selected coordinate plane read 0.000.
INFORMATION
Press the button to temporarily interrupt the function. The display returns to the normal
display status. Press the 0 key again to continue with the function.
Press the button to exit from the function.
Parameter Description
1 - 1 CL_A Angle of the inclined plane on the coordinate plane: X-Y
2 - 1 CL_A Angle of the inclined plane on the coordinate plane: Y-Z
3 - 1 CL_A Angle of the inclined plane on the coordinate plane: X-Z
Press the key to select X-Y, Y-Z or X-Z as the coordinate plane.
To enter the angle of the inclined plane, use the numeric keys
and confirm with the key.
Parameters Description
1A _angle entered Inclined plane: X-Y
2A_angle entered Inclined plane: Y-Z
3A_angle entered Inclined plane: X-Z
