The device must only be installed and operated in a dry and well-ventilated place.
Avoid places close to machines which cause chips or dust.
The installation site must be vibration-free, i.e. located away from presses, planing
machines, etc.
The foundation must be suitable for the milling machine. Pay attention also to the load-bear-
ing capacity and evenness of the floor.
The substructure must be prepared in such a way as to ensure that, if any lubricant is used,
it cannot penetrate the floor.
Protruding parts - such as the dog, handles, etc. - must be secured, where necessary, by
means of on-site measures so that persons are not endangered.
Provide enough space for set-up and operating personnel and material transport.
Also bear in mind accessibility for installation and maintenance works.
Ensure adequate lighting is available (minimum value: 500 Lux, measured at the tool tip). In
the event of a lower level of lighting, additional illumination must be provided, e.g. by means
of a separate workplace light.
INFORMATION
The main switch of the milling machine must be freely accessible.
3.7 Machine mounting
3.7.1 Anchor-free mounting
This must be done by laying down a strong base, on each support of the levelling points,
between the foundation and the machine foot.
3.7.2 Anchored mounting
Use an anchored mounting to achieve a rigid connection to the substructure. An anchored
mounting is always appropriate if the intention is to machine large parts up to the maximum
capacity of the drilling-milling machine.
The milling machine is fastened to the floor with four anchor screws DIN 529 M12 x 320 through
the machine foot. The anchor screws are not included in the delivery.
The dimensions of the anchor screws are shown in the following drawing.
