5.9 Arc
Creates an arc in a coordinate system such that processes can be carried out on said arc.
 The parameters are displayed in the Rotation Speed field.
 The last entered value of each parameter is shown in the row of the X axis.
 Entering a new value is specified in the row of the Y axis.
5.9.1 Entering the parameters
Parameter Description
1 - 1 ACE Midpoint of the arc on the coordinate plane: X-Y
2 - 1 ACE Midpoint of the arc on the coordinate plane: Y-Z
3 - 1 ACE Midpoint of the arc on the coordinate plane: X-Z
Press the key to select X-Y, Y-Z or X-Z as the coordinate plane.
To enter the end midpoint of the arc, use the numeric keys
and confirm with the key.
Parameter Description
1 - 2 5E_d Radius of the arc on the coordinate plane: X-Y
2 - 2 5E_d Radius of the arc on the coordinate plane: Y-Z
3 - 2 5E_d Radius of the arc on the coordinate plane: X-Z
To enter the end radius of the arc, use the numeric keys
and confirm with the key.
