Operation
Version 1.0.4 - 2020-08-0452 Translation of original instruction
DPA21
EN
DPA21_GB_3.fm
Parameter Description
1 - 3 0U_S Machining mode of the arc on the coordinate plane: X-Y
2 - 3 0U_S Machining of the arc on the coordinate plane: Y-Z
3 - 3 0U_S Machining of the arc on the coordinate plane: X-Z
To set machining mode of the arc, use the numeric keys 0 or 1.
0 = Machining mode of the arc from the inside.
1 = Machining mode of the arc from the outside.
Confirm with the key.
Parameters Description
1 - 4 CU_d Milling tool diameter: X-Y
2 - 4 CU_d Milling tool diameter: Y-Z
3 - 4 CU_d Milling tool diameter: X-Z
To enter the diameter of the milling tool, use the numeric keys
and confirm with the key.
Parameter Description
1 - 5 S_Po Start position: X-Y
2 - 5 S_Po Start position: Y-Z
3 - 5 S_Po Start position: X-Z
To enter the start position, use the numeric keys
and confirm with the key.
