4.8 Moving the cross table up / down
Manual movement on the Z axis
The height adjustment of the milling table is carried out with the hand crank.
Loosen the clamping lever.
Engage the hand crank by pressing into the coupling.
Position the milling table on desired position using the crank.
Make sure to tighten the clamping lever again once you have completed the operation.
4.9 Moving the spindle head-holder forward or back
You can move the spindle head-holder forward or back.
Proceed as follows:
Loosen the clamping lever.
Bring spindle head support with a key on the square drive in the desired position.
Imperatively fasten the clamping screws.
4.10 Moving the cross table left or right (X axis)
There are two ways of moving the cross table on the X axis.
By turning the handwheel on the milling table.
With the automatic table feed.
4.10.1 Manual movement on the X axis
To manually move the cross table, the clamping levers are released and the table is moved
with the hand crank.
Loosen the clamping lever.
Engage the hand crank by pressing into the coupling.
Position the milling table on desired position using the crank.
Clamp again if required.
4.10.2 Switching the automatic table feed (X axis) on / off
To automatically move the cross table, the clamping levers are released and the operating
mode "rapid traverse" or "feed" is selected via the selector lever. The movement is activated
with the directional lever.
ATTENTION!
If the speed of the table feed is changed, the direction lever for the feed must be in
neutral middle position (in position "Off“).
ATTENTION!
Loosen the clamping lever on the cross table.
