Chapter 4 - Technical Specification
TABLE 5: Scan head dimensions
Dimension Details
Width 440 mm (18 inches)
Depth 500 mm (20 inches)
Height 795 mm (32 inches)
Weight 28 kg (62 lbs)
Door access width 760 mm (30 inches)
4.1.4 Review client properties
You can review and analyze images using the review software.
TABLE 6: Review client properties
Review clients
Display properties for browser-based review clients.
The minimum recommended monitor resolution. 1280 x 1024 pixels, 16.7 million colors.
Recommended browsers for OptosAdvance.
Google Chrome (46.0 and higher)
Internet Explorer (11.0 and higher)
Apple Safari (6.0 and higher)
Note
If you are using Vantage Review, the minimum recommended monitor resolution also applies to Viewing PCs.
4.1.5 Touch screen properties
The touch screen is powered from the scan head at +12V.
WARNING
Do NOT disconnect or connect the touch screen while the scan head is in use.
TABLE 7: Touch screen properties
Dimension Details
Minimum display resolution 1024 x 768 pixels, 16.7 million colors
Width 260 mm (10.5 inches)
Depth 20 mm (1 inch)
Height 216 mm (8.5 inches)
Weight less than 1 kg
Touch screen mount VESA MIS-D, 75, C (hole pattern: 75 mm x 75 mm)
Part Number: G102748/9GSE Page 53 of 65
Copyright 2017, Optos plc. All rights reserved. English
