ZS3-4 Controller Hardware Overview
12.
Connect data cables to the PCIe card, routing them through the cable
management arm.
13.
When the system has finished booting, log in and set the time using the steps in
the task “Setting Clock Synchronization (BUI)” in Oracle ZFS Storage Appliance
Administration Guide, Release OS8.6.0.
ZS3-4 Controller Hardware Overview
To understand the ZS3-4, see the following topics:
■
“ZS3-4 Base Configuration” on page 111
■
“ZS3-4 Specifications” on page 111
■
“ZS3-4 Front and Rear Panel Components” on page 112
■
“ZS3-4 Internal Components” on page 116
■
“ZS3-4 PCIe I/O Cards” on page 121
■
“ZS3-4 Attached Storage” on page 125
ZS3-4 Base Configuration
The ZS3-4 controller can be configured as a standalone controller or clustered controllers to
create a high-availability cluster configuration. The following table describes the configuration
options:
TABLE 17
ZS3-4 Controller Features
Mktg Part
Number
CPU Memory
Read Cache
SAS-2
Boot Drive
SAS-2
HBA SAS-2
Software
Version (min)
7105725 4x10-core,
2.40GHz
1TB (16GB
DIMMs)
Four 1.6TB Two 900GB 4X4-port 2013.1.0
Refer to the product site at https://www.oracle.com/storage/nas/index.html for the most
recent component specification.
ZS3-4 Specifications
ZS3-4 Physical Specifications - The ZS3-4 controller chassis fits in a standard equipment rack,
and occupies three rack units (3RU) in height. The chassis dimensions are as follows:
Servicing the ZS3-4 Controller 111
