ZS3-2 Controller Hardware Overview
ZS3-2 PCIe I/O Cards
ZS3-2 PCIe I/O Options - The following table describes the supported PCIe configuration
options for the ZS3-2 controller. Slots 1 and 2 are reserved for internal and external HBAs, as
shown in the following table. When adding PCIe cards, populate from higher order slots (6)
first toward lower order slots.
Note - Any empty PCIe slots must have a filler panel installed.
TABLE 27
ZS3-2 Controller PCIe Configuration Options
Slot Mfg Part Number Description Max Note
1 7047852 8-port SAS-2
internal HBA
1 Base configuration
2 7067091 4-port (4x4) SAS-2
external HBA
2 Base configuration
3 7067091 4-port (4x4) SAS-2
external HBA
2 Second 4x4-port
SAS-2 external HBA
3 7070195 4-port 1Gb Ethernet
Copper UTP NIC
4 Optional
recommended front-
end
3 371-4325-02 2-port 8Gb FC HBA 4 Optional FC target or
initiator (backup)
3 7023303 2-port 16Gb FC
HBA
4 Optional FC target or
initiator (backup)
3 375-3696-01 2-port InfiniBand
CX2 HCA
4 Optional
recommended front-
end
3 7051223 2-port 10Gb Ethernet
Optical NIC
4 Optional
recommended front-
end
3 7070006 2-port 10Gb Ethernet
Copper Base-T NIC
4 Optional
recommended front-
end
4-6 7070195 4-port 1Gb Ethernet
Copper UTP NIC
4 Optional
recommended front-
end
4-6 371-4325-02 2-port 8Gb FC HBA 4 Optional FC target or
initiator (backup)
4-6 7023303 2-port 16Gb FC
HBA
4 Optional FC target or
initiator (backup)
4-6 375-3696-01 2-port InfiniBand
CX2 HCA
4 Optional
recommended front-
end
Servicing the ZS3-2 Controller 169
