Chassis Details View
Related Topics
“Disk Shelf Details View” on page 23
Chassis Details View
To view the chassis details, click on the right-arrow icon (or one of the alternative forms
described above). This view includes some of the same controls in the upper left (state, name,
locate, reset, power off), as well as listings of all the components in the chassis.
At the left is a set of images describing the chassis. If there are multiple views, then you can
switch between them by clicking on the name of the view above the image.
For each view, faulted components will be highlighted in red. In addition, the currently selected
component will be highlighted in the image. Clicking on a component within the image will
select the corresponding component in the list to the right.
A tab is present for each component type in the following list. Each component type has a state
icon which will be orange if there is a faulted component of the given type.
Disk
Slot
CPU (controller only)
DIMM (Memory) (controller only)
Fan
PSU (Power supply unit)
SP (Service processor) (controller only)
Clicking on a component type will display a list of all physical locations within the chassis
where components may be present. Clicking on a component within the list will highlight it
within the appropriate chassis image. Clicking on the information icon while over a row or
double-clicking a row will bring up a dialog with detailed information about the component.
The information displayed in the list depends on the component type, but is a subset of the
information available in the component detail. Disks and service processors support additional
operations described below. Each component can report any or all of the following properties:
TABLE 4
Chassis Component Properties
Property Description
Label Human-readable identifier for this component within the chassis. This is
typically, but not necessarily, equivalent to the label printed on the physical
chassis.
22 Oracle ZFS Storage Appliance Customer Service Manual • July 2016
