Disk Shelf Hardware Overview

FIGURE 76

Sun Disk Shelf Power Supply Indicators

Figure Legend Figure Legend

1 Cooling fan status indicator 6 Power cord tie wrap

2 AC power status indicator 7 Universal power input connector

3 DC power status indicator 8 Right ejection arm and captive screw latch

4 Power supply status indicator

5 Power on/off switch

Disk Shelf Drive Locations

The following figures show the location of the drives.

284 Oracle ZFS Storage Appliance Customer Service Manual • July 2016
