ZS4-4 Controller Hardware Overview
Legend for Interconnect Types and Options
- Copper RJ-45 Unshielded Twisted
Pair
ZS4-4 Internal Components
The ZS4-4 chassis contains both customer-replaceable units (CRUs) and field-replaceable units
(FRUs) as shown in the following figure. FRUs must be replaced by trained Oracle service
technicians.
FIGURE 9
Internal Components (Exploded View)
Figure Legend
1 Power supplies (CRU) 8 Memory riser card (CRU)
2 Power supply backplane (FRU) 9 Motherboard (FRU)
3 SP card (FRU) 10 System drive (CRU)
4 HBA/PCIe cards (CRU) 11 Fan module (CRU)
5 CPU (FRU) 12 Fan board (FRU)
6 Heatsink (FRU) 13 Drive backplane (FRU)
7 Cover 14 Chassis
Servicing the ZS4-4 Controller 83
