ZS4-4 Controller Hardware Overview
Slot Description Max Type Note
9 16GB Dual Universal FC HBA 4 B Optional FC target or initiator
(Backup)
10 2-port InfiniBand CX3 HCA 4 A Optional recommended front-
end
10 2-port 10Gb Ethernet Optical
NIC
4 C Optional recommended front-
end
10 2-port 10Gb Ethernet Copper
NIC
4 D Optional recommended front-
end
10 16GB Dual Universal FC HBA 4 B Optional FC target or initiator
(Backup)
11 2-port InfiniBand CX3 HCA 4 A Optional recommended front-
end
11 2-port 10Gb Ethernet Optical
NIC
4 C Optional recommended front-
end
11 2-port 10Gb Ethernet Copper
NIC
4 D Optional recommended front-
end
11 16GB Dual Universal FC HBA 4 B Optional FC target or initiator
(Backup)
The legend describes the interconnect types and option codes shown in the Type column.
Legend for Interconnect Types and Options
A InfiniBand QDR QSFP+
- QSFP Direct Copper Cable
Connect
- Optical Transceiver QSFP Short
Range 40Gbs
E Storage Array 4-port External SAS-2
Mini-SAS HD
- SFF-8644 Mini-SAS HD to Mini-
SAS Copper
B Fibre Channel 16Gb SFP+
- Optical Transceiver SFP Short
Range 16Gbs
F HDD 8-port Internal SAS-2 Mini-
SAS
-SFF-8087 Mini-SAS to Mini-SAS
Copper
C GbE NIC Multi-mode Fiber SFP+
10GBase-SR/LR
- Optical Transceiver SFP Short
Range 10Gbs
- Optical Transceiver SFP Long
Range 10Gbs
G Server Heartbeat 2-port RS-232 1-
port 1GBase-T
-Copper RJ-45 Serial RS-232
-Copper RJ-45 Unshielded Twisted
Pair
D GbE NIC UTP 10GBase-T
82 Oracle ZFS Storage Appliance Customer Service Manual • July 2016
