Disconnecting the RJ-45 Cable from the Cluster Serial Port

Disconnecting the RJ-45 Cable from the Cluster Serial

Port

Using your index finger, press down fully on the RJ-45 release tab. Be sure the

tab is fully disengaged from the port.

Servicing the ZS3-2 Controller 129
