Replacing a ZS3-2 Flash Drive
24.
Go to the Maintenance > Hardware screen of the BUI, and click the right-
arrow icon on the controller. Then, click Slot to verify the status of the new
component. The online icon should be green.
25.
If a fault does not self-clear, see “Repairing Active Problems” on page 37.
Replacing a ZS3-2 Flash Drive
Removing the USB flash drive is a cold-service operation. You must power off the appliance
before you remove the USB. There will be a loss of access to the storage unless the system is in
a clustered configuration.
The USB flash drive is located in the forward-most USB socket at the center rear of the
motherboard, labeled USB 1, near where Riser 2 installs. Use the following procedure to
replace a ZS3-2 flash drive.
1.
Power off the storage controller as described in “Powering Off the
Controller” on page 50.
2.
Extend the controller from the rack as described in “Extending the Storage
Controller from the Rack” on page 51.
3.
Remove the top cover as described in “Removing the Top Cover” on page 52.
4.
If a PCIe card installed in Riser 2 prevents you from accessing the USB drive,
remove Riser 2.
152 Oracle ZFS Storage Appliance Customer Service Manual • July 2016
