Page #18 background image
Electrical Specifications
18 SPARC T5-4 Server Installation Guide • July 2015
Description U.S. Metric
Minimum airflow clearance (rear) 3 in. 76.2 mm
Related Information
“Server Overview” on page 12
“Handling Precautions” on page 26
“Installing the Server”
“Electrical Specifications” on page 18
“Environmental Requirements” on page 19
“Airflow Precautions” on page 20
Electrical Specifications
Use these specifications only as a general planning guide. To determine power values based on
expected workloads, use theSPARC T5-4 power calculator located at this online site:
http://www.oracle.com/goto/powercalculators/
Description Value
Operating input range 200 to 240 VAC,
50-60 Hz
Maximum operating input current at 200 VAC
(Actual amperage draw may exceed rating by no more than 10%)
15.3 A
Maximum operating input power at 200 VAC
(Actual power draw may exceed rating by no more than 10%)
3000W
Maximum heat dissipation 11,233 BTU/hr 11,851
KJ/hr
Maximum standby power 140W
Maximum server configuration specification under nominal temperature and voltage
conditions:
(Four 3.6GHz T5 Processors, with sixty-four 32GB DDR3 DIMMS, 8 HDD and 16 I/O
cards)
Idle input power 1495 W
Peak AC input power (running SpecJBB) 3292 W
Minimum server configuration specification under nominal temperature and voltage
conditions
(Two 3.6GHz T5 Processors, with 32x 16GB DDR3 DIMMS, no HDD and no I/O cards)
