Rack Compatibility
30 SPARC T5-4 Server Installation Guide • July 2015
Rack Compatibility
The rackmount kit is compatible with equipment racks that meet the following standards.
Item Requirement
Rack types when used with the CMA comb,
part number 7069793
1000-mm and 1200-mm racks
Rack type when used with the multi-piece
CMA, part number 7041990
1200-mm rack only.
Structure Four-post rack (mounting at both front and rear). Two-post racks
are not compatible.
Rack horizontal opening and unit vertical pitch Conforms to ANSI/EIA 310-D-1992 or IEC 60927 standards.
Rack rail mounting hole sizes 9.5-mm square holes, M6 round mounting holes and 10-32
mounting holes are supported. All other sizes, including 7.2-mm or
M5 mounting holes, are not supported.
Distance between front and rear mounting
planes
Minimum: 24 in. (240 mm)
Maximum: 36 in. (915 m)
Clearance depth in front of front mounting
plane
Distance to front rack door is at least 1 in. (25.4 mm).
Clearance depth behind front mounting plane Distance to rear rack door is at least 34.6 in. (878.8 mm) with the
cable management arm, or 31.5 in. (800 mm) without the cable
management arm.
Clearance width between front and rear
mounting planes
Distance between structural supports and cable troughs is at least
18.9 in. (480 mm).
Server dimensions Depth: 31.5in. (800 mm)
Width: 17.5 in. (445 mm)
Height: 8.5 in. (215 mm)
Related Information
■
“Physical Specifications” on page 17
■
“Tools Needed for Installation” on page 27
■
“Determine Correct Rackmount Hardware” on page 36
■
“Rackmount Kit (Part number 7069640)” on page 32
■
“Rackmount Kit (Part number 350-1662-02)” on page 34
