Determine Correct Shipping Brace Fasteners
50 SPARC T5-4 Server Installation Guide • July 2015
Determine Correct Shipping Brace Fasteners
Determine the correct fasteners for your shipping brace installation.
Rack Type Fastener Bags Required
Square hole with corner bezel SCREW, SEMS, M6 X 16MM
SCREW, SEMS, M6 X 30MM
Tapped hole (10-32) SCREW, SEMS, 10-32 X 1-1/4”
SCREW, SEMS, 10-32 X 10MM
Tapped hole (M6) SCREW, SEMS, M6 X 16MM
SCREW, SEMS, M6 X 30MM
Install the Top Rear Braces
Before You Begin
The rear braces are labeled left and right as viewed from the rear of the rack.
1.
Install two cage nuts into the left rear rack post above the adapter bracket.
2.
Position the top left brace on the left rear rack post above the adapter.
3.
Insert and finger-tighten the guide pin in the appropriate hole for your server.
4.
Secure the brace with two M6 x 12-mm screws.
