Connect Other Data Cables
64 SPARC T5-4 Server Installation Guide • July 2015
1.
Connect a Category 5 (or better) cable from your network switch or hub to
Ethernet Port 0 (NET0) on the rear of the chassis.
2.
Connect Category 5 (or better) cables from your network switch or hub to the
remaining Ethernet ports (NET1, NET2, NET3) as needed.
Related Information
■
Servers Administration
■
“Powering On the Server for the First Time”
Connect Other Data Cables
If the server is configured with additional I/O components, connect the external
cables to the connectors contained on those components.
Related Information
■
PCIe card documentation
■
Server Service
Secure Cables Using the CMA
Use the CMA to secure cables and ensure proper cable routing.
1.
Remove the CMA cover.
