Install the CMA Comb
44 SPARC T5-4 Server Installation Guide • July 2015
Install the CMA Comb
You will be installing the single-unit CMA comb. For installation of the multi-piece CMA, see
“Install the CMA (Multi-piece CMA)” on page 46.
The CMA is attached to the rear posts of the rack.
Note - The CMA installation might block some of the power outlets in the rack, making them
unavailable.
1.
Confirm that you have the correct hardware to install the CMA (“Determine
Correct Rackmount Hardware” on page 36).
2.
At the front of the system, remove four screws, two per side.
3.
At the rear of the system, on square hole racks, remove the middle adapter
screw on each side and push the system forward 3 in. (76 mm).
Caution - Do not remove the top adapter screw on the square hole racks.
4.
Attach the left and right CMA brackets to the comb, using three M6 screws per
side.
5.
Attach the CMA comb to the rack posts, using two M6 screws per side.
6.
At the front of the system, push the system back until it touches the rails.
