Identifying Ports
Connecting the Server Cables 57
Identifying Ports
■
“USB Ports” on page 57
■
“SER MGT Ports” on page 58
■
“NET MGT Port” on page 59
■
“Gigabit Ethernet Ports” on page 60
■
“VGA Port” on page 60
Related Information
■
“Server Overview” on page 12
■
“Front Panel Components” on page 13
■
“Rear Panel Components” on page 14
■
“Cabling Requirements” on page 55
■
“Connecting Data and Management Cables” on page 61
USB Ports
Two USB 3.0 ports are located at the rear panel. Two additional USB 3.0 ports are located on
the main module and are accessible from the front panel. See the location of the USB ports at
“Front Panel Components” on page 13 and “Rear Panel Components” on page 14. The USB
ports support hot-plugging. You can connect and disconnect USB cables and peripheral devices
while the server is running without affecting server operations.
Each USB port supplies 5V output at 500 mA.
