Determine Correct Rackmount Hardware
36 SPARC T5-4 Server Installation Guide • July 2015
Determine Correct Rackmount Hardware
Determine the hardware needed for your rack installation.
Rack Type Fastener Bags Required
Square hole SCREW, SEMS, M6 X 16
CAGE NUTS, M6
SCREW, FLAT HEAD, M4 X 10
Round hole (10-32) with corner bezel SCREW, SEMS, 10-32 X 10
SCREW, FLAT HEAD, M4 X 10
Round hole (M6) with corner bezel SCREW, SEMS, M6 X 12
SCREW, FLAT HEAD, M4 X 10
Round hole (10-32) inside installation SCREW, SHOULDER, 10-32
SCREW, FLAT HEAD, M4 X 10
Round hole (M6) inside installation SCREW, SEMS, M6 X 12
SCREW, FLAT HEAD, M4 X 10
Note - Some of the fastener bags that are included in the kit are not required to install this
server.
Related Information
■
“Rackmount Kit (Part number 7069640)” on page 32
■
“Rackmount Kit (Part number 350-1662-02)” on page 34
■
“Rack Compatibility ” on page 30
■
“Mark the Rackmounting Location” on page 36
■
“Install the Rackmount Hardware” on page 37
Mark the Rackmounting Location
Use the Rack Buddy template to identify the correct mounting holes for the shelf rails.
Note - Load the rack from bottom to top.
1.
Ensure that there is enough vertical space in the rack to install the server.
2.
Place the Rack Buddy template against the front rails.
