Rackmount Kit (Part number 350-1662-02)
34 SPARC T5-4 Server Installation Guide • July 2015
No. Description
12. M6 16-mm screws (12)
Related Information
■
“Rackmount Kit (Part number 350-1662-02)” on page 34
■
“Tools Needed for Installation” on page 27
■
“Install the Rackmount Hardware” on page 37
■
“Rack Compatibility ” on page 30
■
“Determine Correct Rackmount Hardware” on page 36
Rackmount Kit (Part number 350-1662-02)
This rackmount kit includes the multi-piece CMA. If your rackmount kit includes the CMA
comb, see “Rackmount Kit (Part number 7069640)” on page 32.
The rackmount kit has two shelf rails, one for each side of the rack. Each shelf rail is marked
LEFT or RIGHT.
The shelf rails are mounted to the rack or rack with four adaptor brackets. The shelf rails adjust
to fit rack depths from 25 to 34.25 in. (63.5 to 87 cm).
