OPTIONAL HD-SDI I/O BOARD
PART # DESCRIPTION COMPONENT IDENTIFIER
28045.250.01.1 Crystal 25.000MHZ 18PF SMD Y902
28045.200.01.1 Crystal 20.000MHZ 18PF SMD Y900
27115.000.01.1 Connector BNC RA 6GHZ 75Ω J200, J201
24796.300.01.1
IC FPGA VERTEX5 30K
665FPGA
U700
21198.225.01.1
Capacitor Ceramic 2.2UF 6.3V
0805
C717, C718, C720, C721, C723, C724,
C744, C745, C746, C747, C761, C762,
C763, C764, C765, C766
21197.475.01.1
Capacitor Ceramic 4.7UF 6.3V
0402
C204, C209, C210, C211, C213, C214
21197.224.01.1
Capacitor Ceramic 0.22UF 6.3V
0402
C715, C716, C719, C722, C725, C726,
C727, C728, C729, C730, C731, C732,
C733, C734, C735, C736, C737, C738,
C739, C740, C741, C742, C743, C748,
C749, C750, C751, C752, C753, C754,
C755, C756, C757, C758, C759, C760,
C767, C768, C769, C770, C771, C772,
C773, C774, C775, C776, C777, C778,
C779, C780, C781, C782, C783, C784,
C785, C786, C787, C788, C789
21197.105.01.1
Capacitor Ceramic 1UF 6.3V
0402
C208, C212
21194.103.01.1
Capacitor Ceramic 0.01UF 25V
0402
C215, C216, C217
20169.750.01.1 Resistor 750Ω 1/16W 1%0402 R211
20169.499.01.1 Resistor 49.9Ω 1/16W 0402 R208, R209
20169.374.01.1 Resistor 37.4Ω 1/16W 0402 R204
20169.153.01.1 Resistor 1.5KΩ 1/16W 0402 R210
20169.075.01.1 Resistor 75Ω 1/16W 1% 0402 R200, R201, R202, R203, R205, R206, R207
29551.000.01.1
Inductor Ferrite 220K 2000MA
0805
L1100, L1101, L1102, L1103, L1104, L1105,
L1106, L1107, L1108, L1109, L1110, L1300,
L1301, L1400
29540.000.01.1 BEAD Ferrite 100MHz 80ohm
L303, L304, L305, L306, L307, L308, L309,
L310, L312, L313, L314, L315, L1001, L1002
29539.000.01.1 Choke Common-Mode 1KΩ SM
L109, L110, L300, L301, L302, L311, L316,
L317, L1000
29537.102.01.1 Inductor 0805 Ferrite 1000-Ohm
L100, L318, L319, L320, L321, L322, L323,
L400, L401, L402, L403, L1003, L1004,
27426.003.01.1
Connector Header 3PIN SNGL
RW
J301, J302, J304, J305, J307, J308, J1000
29015.000.01.1
AES3id Transformer, surface-
mount
T300, T301, T302, T303, T304, T305, T1000
21330.000.01.1
Capacitor Tantalum 330uF 2.5V
20% L
C709, C810, C1108, C1109, C1110, C1111,
C1304
21329.000.01.1
Capacitor Tantalum 47uF 6.3V
20% Surface Mount
C700, C701, C702, C703, C704, C705,
C706, C707, C708
21328.000.01.1
Capacitor Tantalum 33uF 6.3V
20% Surface Mount
C710, C1317
21325.610.01.1
Capacitor 10UF 10% Tantalum
3528
C104, C108, C218, C220, C315, C316,
C321, C324, C329, C332, C337, C340,
