TECHNICAL DATA ORBAN MODEL 8685
OPTIONAL HD-SDI I/O BOARD
PART # DESCRIPTION COMPONENT IDENTIFIER
C341, C342, C343, C344, C345, C400,
C403, C406, C409, C503, C600, C606,
C806, C814, C900, C901, C902, C908,
C917, C918, C1009, C1012, C1017, C1200,
C1201, C1206, C1309, C1310, C1314,
C1402, C1411, C1412
24769.000.01.1
IC 4-Channel Asynchronous
Converter
U301, U303, U305, U400, U401, U402,
U403, U1002
24676.000.01.1 IC Transistor CS8427 28 PIN U1001
21192.000.01.1
Capacitor Ceramic 3300pf 50V
5% C0G
C631
21190.000.01.1
Capacitor Ceramic 10uf 25V
LOW ESR
C809
21186.000.01.1 Capacitor 22000pF COG 0805 C222, C1007
21177.000.01.1 Capacitor 0805 0.22UF X7R
C1003, C1120, C1121, C1122, C1123,
C1124, C1125, C1126, C1127, C1128,
C1129, C1130, C1302, C1303
21171.105.01.1 Capacitor 1uf X7R 0805
C100, C200, C612, C616, C619, C638,
C811, C913, C914, C915, C916, C1311
21146.310.01.1
Capacitor 0.01uf 0805 10%
0805
C207, C910, C912, C920, C1005
21143.000.01.1
Capacitor NPO 1500PF 1%
0805
C118, C119, C1006
21139.000.01.1 Capacitor X7R 0.1UF 10% 0805
C101, C102, C103, C105, C106, C107,
C109, C110, C111, C114, C115, C205,
C219, C221, C223, C300, C301, C302,
C303, C304, C305, C306, C307, C308,
C309, C310, C311, C312, C313, C314,
C317, C318, C319, C320, C322, C323,
C325, C326, C327, C328, C330, C331,
C333, C334, C335, C336, C338, C339,
C401, C402, C404, C405, C407, C408,
C410, C411, C500, C501, C502, C504,
C505, C506, C507, C602, C603, C608,
C609, C610, C611, C613, C622, C623,
C624, C627, C628, C629, C630, C633,
C635, C640, C711, C712, C713, C714,
C790, C800, C801, C802, C803, C804,
C805, C807, C808, C812, C813, C815,
C903, C904, C905, C906, C907, C909,
C911, C919, C1000, C1001, C1002, C1004,
C1008, C1010, C1011, C1013, C1014,
C1015, C1016, C1104, C1105, C1106,
C1107, C1116, C1117, C1118, C1119,
C1202, C1203, C1204, C1205, C1207,
C1208, C1209, C1210, C1211, C1212,
C1213, C1214, C1301, C1308, C1318
(C1403, NO STUFF)
20242.000.01.1
Resistor Network 47K 5% 4-
Resistor Surface-Mount
RN1001
20241.000.01.1
Resistor Network 47ohm 5% 4-
Resistor Surface-Mount
RN300, RN301, RN302, RN700, RN701,
RN702, RN703, RN704, RN705, RN706,
RN707, RN806, RN808, RN1000
