Orban OPTIMOD 8685 - Page 287

OPTIMOD SURROUND PROCESSOR TECHNICAL DATA
6-31
OPTIONAL HD-SDI I/O BOARD
PART # DESCRIPTION COMPONENT IDENTIFIER
20239.000.01.1
Resistor Network 47ohm 5% 8-
Resistor Surface-Mount
RN200, RN800, RN801, RN802, RN803,
RN804, RN805, RN807
21138.247.01.1
Capacitor SMD1206 4700PF
50V 5%
C615
20166.051.01.1 Resistor 1/4W 5.1Ω 1% R900, R906, R909
20132.619.01.1
Resistor 1/8W 1% 619 ohm
0805
R901, R905, R907, R908
20130.475.01.1 Resistor 4.75K 0805 R614, R615, R619, R620, R717, R718, R802
20135.002.01.1 Resistor 5% 2Ω 0805 R324, R325, R326, R1013
20132.100.01.1 Resistor 1/8W 1% 100K R0805 R216, R1003
20131.100.01.1 Resistor 10K 0805
R100, R129, R130, R221, R502, R507,
R510, R511, R600, R604, R607, R618,
R701, R733, R1005, R1006, R1009 (R721,
R902, NO STUFF)
20130.249.01.1 Resistor 1/8W 1% 2.49K 0805 R512, R513, R602
20129.332.01.1 Resistor 332Ω 1% 0805 R716
20129.100.01.1 Resistor 100Ω 0805
R217, R719, R729, R800, R801, R1100,
R1101, R1102, R1103, R1300 (R219, NO
STUFF)
20129.301.01.1 Resistor 301Ω 0805 R903, R904, R910, R911
20129.110.01.1 Resistor 0805 110Ω 1% 1/8W R127, R128, R303, R312, R322
20129.604.01.1 Resistor 0805 604Ω 1% 1/8W R1001
20130.100.01.1 Resistor 1.00K 1% 0805
R220, R503, R504, R505, R506, R508,
R509, R714, R715, R726, R727
20128.499.01.1 Resistor 49.9Ω 1% 0805
R302, R305, R306, R308, R311, R315,
R316, R317, R319, R320, R321, R323,
R400, R401, R402, R403, R404, R405,
R406, R407, R623, R624, R700, R702,
R703, R704, R705, R706, R707, R708,
R709, R710, R711, R712, R713, R720,
R723, R724, R728, R730, R731, R732,
R1004, R1007, R1008, R1010, R1011,
R1012, R1112, R1200, R1415 (R722, R725,
NO STUFF)
20128.075.01.1 Resistor 75Ω 1% 0805 R215, R301, R310, R313, R612, R1000
24348.000.01.1
IC Regulator Synchronous Buck
Clk 4a
U600, U601, U603, U604
27186.000.01.1
Socket SIMM 72tin Left-
Polarized
J1200, J1201
27473.000.01.1
Connector Header Dual Row
2X7 2mm
J700
24979.000.01.1 IC BAT54C-7 D200, D501, D502
23214.000.01.1 Transistor NPN MMBT3904 Q200, Q500, Q700, Q701
24792.128.01.1 IC PIC24FJ128GA106 MCU U500
44126.000.01.1
Firmware IC
PIC24FJ128GA106
U500
44125.000.01.1 Firmware IC FPGA VIRTEX-5 U700
24732.000.01.1 IC Video Sync Separator HDTV U203
