TECHNICAL DATA ORBAN MODEL 8685
OPTIONAL HD-SDI I/O BOARD
PART # DESCRIPTION COMPONENT IDENTIFIER
29550.000.01.1
Inductor Shielded PWR 680uH
760mA
L602, L603
24798.000.01.1
IC DDR SDRAM 512MB 66-
TSO
U800, U802
24680.000.01.1
IC GS2974ACNE Cable Equal-
izer
U200
24679.000.01.1 IC GS2978-CNE3 U201
24349.000.01.1 IC Regulator LDO 1.5A 10-DFN U1100, U1101, U1102, U1103, U1300
24797.000.01.1 IC PROM 1.8V 16M 48TSOP U701
24420.000.01.1
IC Octal Edge-Triggered Type D
Flipflop
U1200, U1201, U1202, U1203
24419.000.01.1 IC 3-8 Line Decoder/Demux U501, U502
28099.000.01.1 Crystal 32.768 KHZ 12.5pf SM Y200
27459.006.01.1
Header 1X6 .100 PC Mount
W/LK
J500
29544.000.01.1 EMI Filter 1000pF 50V 080 L105, L106, L107, L108
29541.000.01.1 Inductor 3.3UH Power SMD L101, L102, L103, L104
25102.000.01.1 LED Yellow CLR 1206 D500, D700, D701
27451.007.01.1
Connector Double Row PC MNT
40 PIN
J601, J602
24768.000.01.1
IC 2-Channel Asynchronous
Converter
U300, U302, U304, U1000
27057.000.01.1
Connector DUAL BNC PC
Mount, Internal Capacitor
J202, J300, J303, J306
27451.004.01.1
Header STR Double Row PC-
Mount
J502, J600
27406.014.01.1 Connector Socket Strip 14 PIN J603
27147.008.01.1 IC Socket DIP 8 Pin Dual SU104, SU105
27053.003.01.1
Connector Male Insert Right An-
gle
J100, J101
24997.000.01.1 IC DAC AK4393VSP VSOP U100
24960.000.01.1 IC OPA2134UA U101, U102, U103
24958.000.01.1 IC DRV134PA U104, U105
24347.000.01.1
IC Regulator Low-Dropout 3.3V
1.5A SOT2
U901
24345.000.01.1
IC Regulator 3A Sink/Source
DDR 10
U801
21191.000.01.1
Capacitor Ceramic 2200PF 50V
5% COG
C636
21189.000.01.1
Capacitor Ceramic 47uF 10V
X5R 20%
C604, C605, C625, C626, C1100, C1101,
C1102, C1103, C1300
21188.000.01.1
Capacitor Ceramic 100uF 6.3V
X 5R 2
C618, C620, C621, C639
21185.220.01.1
Capacitor 22uF 6.3V X5R 20%
080
C1112, C1113, C1114, C1115, C1307
21175.000.01.1
Capacitor 6800pF 10% X7R
0805
C614, C617, C632, C634, C637
22106.000.01.1 Diode VSTT SMCJ26 DO214 CR100, CR101, CR102, CR103
