Oriental motor BLH Series - Dimensions

146
Specications
18.3 Dimensions
Mass: 46 g (1.62 oz.) [Unit: mm (in.)]
34.5±0.2
(1.358±0.008)
6 (0.236)
55 (2.17) max.
4 (0.157) 63±0.2 (2.480±0.008)
72 (2.83) max.
3.5 (0.138)
64±0.2 (2.520±0.008)
3.5 (0.138)
22±0.2
0.866
±0.008
27 (1.06) max.
[50 (1.97)]
2×
ϕ
3.5 (
ϕ
0.138) Thru
Installation of motor cable
( )
