Flashing LED Error/warning Cause Possible corrective action
Fault on an actuator (seat
function adjustment
motor)
e.g.defective cable,
loose plug connection to
actuator
Check cabling/plug connections to
defective actuator
TEN°control panel; TEN°LCD module
Display Error/warning Cause Possible action
Emergency stop Serious control
ler/handheld control
device and/or drive
motor malfunction
Check cabling/plug contacts
Contact qualified personnel
Joystick warning
(Center Joystick)
Joystick not in neutral
position when the unit
is turned on
Move the joystick to the neutral
position before switching the unit
on
Defective joystick
(Joystick Error)
Message continues to
be displayed despite
moving joystick to
centre position
Contact qualified personnel
Message window for
serious errors
Causes of the respect
ive error messages: see
following table
Actions for the respective error
messages: see following table
Message window for
warnings
(Error message
examples: see next two
lines)
Causes of the respect
ive warning messages:
see following table
Actions for the respective warning
messages: see following table
Controller temperature
warning (lights up red)
Overheating due to
excessive load
Cool down phase
Motor temperature
warning (lights up red)
Overheating due to
excessive load
Cool down phase
Errors and warning messages in the message window on the TEN°control panel or TEN°LCD module
Error message Error no. Contents Cause Possible action
Center Joystick See previous table
Joystick Error See previous table
Low Battery (None) Battery undervoltage Battery deep dis
charge
Charge as soon as
possible
High Battery (None) Battery overvoltage Voltage too high
Loose battery con
tacts
Continue driving
slowly
Check cabling/plug
connections; if error
persists, contact
qualified personnel
M1 Brake Error 1505 Brake error on left
motor
e.g.defective plug
connection, cable
Check plug connec
tions and cable to
M2 Brake Error 1506 Brake error on right
motor
break
Defective brake
brake
112
Maintenance and repair
490E75=1_C
