Otto Bock 490E75 1 C Series User Manual

7.6.4.5.2 Pairing
INFORMATION
The name of the connected device (display name) can be customised by the qualified personnel (e.g.first name
of the user, here "Tom").
Mutual authentication is required prior to initial Bluetooth communication between devices. This procedure, which
needs to be carried out once for each device, is called "pairing".
The procedure, which can also be carried out by an attendant if necessary, is described below.
Pairing with a PC
INFORMATION
Because of the various operating system versions, some steps (searching for a Bluetooth device, adding a
Bluetooth device, establishing a connection to the Bluetooth device) can only be described in very general terms.
Also use the respective operating system help.
To pair with a PC, perform the following steps:
41
42
>
Prerequisites:
The device registration has been activated (see
page47).
Bluetooth devices can establish a connection to this
computer. If necessary, right-click the Bluetooth
symbol on the Windows interface of the PC (in the
symbols at the bottom right next to the time) ->
Open settings -> Tick checkbox (see fig.41).
1) Turn on the wheelchair control device.
2) Select the "Bluetooth Devices" mode:
→ TEN° control panel: Press the [Profile/Mode]
button a number of times if necessary.
→ TEN°LCD module: Press the [Mode] button a
number of times if necessary.
→ A list of the available options for connecting to
devices is displayed.
3) Start the pairing process by selecting a compatible
device name, e.g.Tom's laptop (to scroll through
the list: move forward/back; to select an item: move
to the right)
→ The laptop symbol is displayed (see fig.42).
4) Move the input device forwards for approx.
10seconds until an acoustic signal sounds.
5) Move the input device back for approx. 10seconds
until an acoustic signal sounds.
→ The Bluetooth symbol at the top of the LCD
screen (next to the time) should flash. The TEN°
control device is ready to establish a connec
tion.
6) Right-click the Bluetooth symbol on the PC (in the
symbols at the bottom right next to the time) ->
Open settings -> Add device.
7) Wait until the device name selected in step 3 is dis
played in the "Add device" PC window and confirm.
The pairing is now performed.
INFORMATION: If additional Bluetooth devices
are nearby, these are also displayed.
48
Use
490E75=1_C
