Display Information
Select the command which needs to be learned, e.g.[Volume down].
Select [Learn code].
Point the TV remote control towards the control panel or TEN°LCD module and
press the desired button (e.g.[Volume down]) twice in succession. The learning pro
gress is displayed on the control panel or TEN°LCD module in learning mode.
INFORMATION: Hold the remote control at a distance of 40 to 100mm (1.57"
to 3.94") away from the receiver for infrared signals.
The receiver is located on the front side of the TEN°control panel or TEN°LCD
module above the LCD screen (see arrow).
Notice: The illustration shows the receiver for infrared signals on the TEN° control
panel.
A tick mark indicates that the learning process was successful.
If the learning process was not successful, an X is displayed. Repeat the learning
process in this case.
7.6.4.6.3 Activating and deactivating IR codes
The learned IR codes can be activated or deactivated:
• Once an IR code is deactivated, it no longer appears in the user menu. The corresponding command
(e.g.[Volume down]) can no longer be transmitted or executed.
• If an IR code is activated, it appears in the user menu. The corresponding command (e.g.[Volume down]) can
be transmitted and executed.
LCD screen in "Settings" menu
Display Information
TEN°control panel: Open the "Settings" menu by pressing and holding the [Warn
ing flashers on/off] button.
TEN°LCD module: Open the "Settings" menu by pressing the [Settings] button.
Using the respective installed input device (e.g.joystick, up/down and right/left nav
igation buttons on the TEN°LCD module, special control input devices), select the
menu item [IR Setup].
54
Use
490E75=1_C
