61
The power seat height adjustment feature raises the
seat bottom by 350mm (13.8") using a motor drive.
The seat can be moved up continuously to the height
specified.
The driving function can be used indoors even when the
seat is raised. The speed is decreased when the seat is
raised (see previous section).
7.11.4 Power seat tilt
WARNING
Incorrect seat tilt handling
Falling, tipping over due to driving with unallowable seat settings
► Use the seat tilt feature only with the backrest in the upright position.
► Drive in street traffic only with the seat tilt lowered.
► When driving with the seat tilt activated, even at home, fasten the belts and do not lean out beyond the seat
surface.
INFORMATION
► Please also observe the generally applicable safety instructions in the section "Power seat functions" >
"Safety instructions" (see page73).
► Observe the instructions for use in the sections "Controlling power seat functions" (see page77) and "Joy
stick functions" (see page79).
62
The power seat tilt function allows the seat to be tilted,
forexample to relieve pressure.
Two different power seat tilt versions are available:
• Power seat tilt up to 45° (with centre of gravity shift
ing)
• Power seat tilt up to 20° (without centre of gravity
shifting)
The seat can be tilted back continuously to the spe
cified angle.
7.11.5 Combined seat height adjustment/seat tilt
This function allows the seat to be tilted while continuously raising the seat surface at the same time.
For further information on the functions and relevant safety information, see the preceding section.
7.11.6 Power back angle adjustment
WARNING
Incorrect use of back angle adjustment
Falling, tipping over due to driving with unallowable seat settings
► Drive in street traffic only with a vertical backrest.
► When driving with the back angle adjustment activated, even at home, fasten the belts and do not lean out
beyond the seat surface.
75490E75=1_C
