CAUTION
Securing the power wheelchair insufficiently during transport
Crushing, pinching of body parts due to failure to observe transportation instructions
► During transportation in vehicles or aircraft, on lifting platforms or in lifts, turn the control unit of the power
wheelchair off and lock the brake.
► The power wheelchair must be secured in accordance with the regulations for the transport device.
► During transport in a vehicle, the power wheelchair must be secured sufficiently with cargo straps. Only
attach the cargo straps to the corresponding transportation eyelets and specified tie-down points.
NOTICE
Lifting the power wheelchair incorrectly
Damage to the power wheelchair due to failure to observe transportation instructions
► Hoisting devices used for transportation must have a sufficient capacity. For more information about weight,
see the section "Technical data" (see page117).
► Do not attach the hoisting devices on moveable or adjustable components.
► Ensure that the seat is lowered all the way and the backrest is in a vertical position prior to loading and for
transporting the power wheelchair.
7.17.2 Reducing the transportation size
The transportation size can be reduced in a few steps to make transporting the product easier.
92
Preparing for transport
1) Fold the backrest forward and onto the seat surface
(see page23).
2) Remove the side panels (see page17). Place the
side panel on the seat.
3) Remove the legrests (see page20).
93
Preparing for transport
1) Fold the backrest forward and onto the seat surface
(see page23).
2) Remove the side panels (see page17). Place the
side panel on the seat.
3) Remove the legrests (see page20).
98
Use
490E75=1_C
