8.7.6 Voltage Protection Programming Commands
Command Syntax
[SOURce:]PROTect:PEAK:VOLTage:MODE <MARGin|LEVel|BOTH>
Description
This command sets the maximum voltage peak margin. If the output
voltage peak exceeds the programmed peak level by more than this
amount, an error is tripped.
Parameters
<MARGin | 0 | LEVel | 1 | BOTH | 2 >
Encoding:
MARGin 0 Relative level
LEVel 1 Absolute level
BOTH 2 Both
Parameter Format
<cr> | <nr1>
Example
PROT:PEAK:VOLT:MODE BOTH
Query Format
[SOURce:]PROTect:PEAK:VOLTage:MODE?
Returned Data Format
<nr2>
Query Example
PROT:PEAK:VOLT:MODE?
2
Command Syntax
[SOURce:]PROTect:PEAK:VOLTage:MARGin <VOLTAGE MARGIN>
Description
This command sets the maximum voltage peak margin. If the output
voltage peak exceeds the programmed peak margin by more than
this amount, an error is tripped.
Parameters
<VOLTAGE MARGIN>
Parameter Format
<nr2>
Example
PROT:PEAK:VOLT:MARG 120.0
Query Format
[SOURce:]PROTect:PEAK:VOLTage:MARGin?
Returned Data Format
<nr2>
Query Example
PROT:PEAK:VOLT:MARG?
120.000
Query Syntax
[SOURce:]PROTect:PEAK:VOLTage:MARGin:MINimum?
Description
This command returns the minimum voltage peak margin setting.
Query Example
PROT:PEAK:VOLT:MARG:MIN?
0.000
Query Syntax
[SOURce:]PROTect:PEAK:VOLTage:MARGin:MAXimum?
Description
This command returns the maximum voltage peak margin setting
Query Example
PROT:PEAK:VOLT:MARG:MAX?
500.000
Query Syntax
[SOURce:]PROTect:PEAK:VOLTage:MARGin:DEFault?
Description
This command returns the default voltage peak margin setting
Query Example
PROT:PEAK:VOLT:MARG:DEF?
100.000
