B) An Error event will be triggered in the error and event queue in order to notify the user.
The error message is:
"Peak current limit setting is too low for the desired voltage and frequency."
as shown in the screen capture below.
6.4.9 Sine Waveform
The ADF Series® support only sinewave output.waveforms. Preview of the sinewave is
shown on the LCD screen.
Name Description Image Notes
1
SINE
Standard sine wave.
Table 6-5: ADF Series® Sine Waveform
