ADF SERIES® OPERATION MANUAL
SECTION 4: TECHNICAL SPECIFICATIONS
Entire Contents Copyright  2018 by Pacific Power Source, Inc. (PPS) • All Rights Reserved • No reproduction without written authorization from PPS.
ADF Series Power Source Operation Manual Page 33 of 349
4.7 AC Input
AC INPUT 9kVA 15kVA
Frequency Range
AC Input Frequency
47 - 63 Hz
Connection
4 Wire, (L1, L2, L3 and PE)
-208 Input Version (-2)
Input Voltage Range
208 Vac – 240 Vac ± 10%
Nominal Phase Current @ 208V 3ø
33 A rms
51 A rms
Max. Rated Phase Current, 3ø
37 A rms
55 A rms
Peak Inrush Current
1
< 1.5 x Irms
Input Power Factor
> 0.9
Efficiency
> 85 %
Internal Line Fuses -2 NOT USER SERVICEABLE
Type
FUSE, SEMICONDUCTOR,22X58MM
Rating
80A,600VAC
-400 / -480 Input Version (-4)
Input Voltage Range
380 Vac – 480 Vac ± 10%
Nominal Phase Current @ 380V 3ø
18 A rms
27 A rms
Max. Rated Phase Current
20 A rms
30 A rms
Nominal Phase Current @ 480V 3ø
14 A rms
23 A rms
Max. Rated Phase Current
16 A rms
28 A rms
Peak Inrush Current
2
< 1.5 x Irms
Input Power Factor
> 0.9
Efficiency
> 85 %
Internal Line Fuses -4 NOT USER SERVICEABLE
Type
FUSE, SEMICONDUCTOR,22X58MM
Rating
63A,600VAC
NOTE: For models consisting of multiple chassis, power input ratings apply to each chassis.
4.8 Dimensions & Weight
DIMENSIONS & WEIGHT 9 kVA 15 kVA
Dimensions
Height
7.0” / 178 mm / 4U
Width
17.0” / 432 mm – w/o rack handles
19.0” / 483 mm - with attached rack handles
Depth
25.0” / 635 mm
Weight
Net
111.2lbs. / 50.4 kg
Shipping
130 lbs. / 59 kg
NOTE: For models consisting of multiple chassis, multiply weight and height by the number of chassis.
See dimension drawing. 3D Step Models Available on request.
1
For nominal line input voltage
2
For nominal line input voltage
