Do NOT connect the RJ45 LAN (Ethernet) connector of the power source to a PoE
(Power over Ethernet) port as the DC voltage will damage the LAN interface.
No special device drivers are required to use the LAN interface as it uses TCP/IP protocol but
the IP address needs to be configured to operate on the user’s local area network or private
network.
Figure 5-22: ADF Series® Rear Panel Layout
