4.6 Metering
MEASUREMENTS
Voltage AC
(1)
Range
L-N: 0 – 350 V rms; L-L: 0 – 600 V rms
Resolution
0.01 V
Accuracy
± 0.25% F.S.
Frequency (AC Mode Only)
Range
15 – 1200Hz
Resolution
0.01 Hz
Accuracy
± 0.1% Reading
Current AC
(2)
Range
See model table in section 4.1 or 0
Resolution
0.01 A
Accuracy
± 0.5% F.S.
Peak Current
Range
4 x RMS current
Resolution
0.01 A
Accuracy
± 1.5% F.S.
Crest Factor
Range
1.00 – 5.00
Resolution
0.01
Accuracy
± 2.0% F.S.
True Power
(2,)
Range
See model table in section 4.1 or 0
Resolution
0.01 W
Accuracy
± 1.5% F.S.
Apparent Power
(2)
Range
See model table in section 4.1 or 0
Resolution
0.01 VA
Accuracy
± 1.5% F.S.
Power Factor
(3)
Range
0.00 – 1.00
Resolution
0.01
Accuracy
± 0.5% F.S.
Voltage DC (Requires Option D)
Range
0- 440 Vdc
Resolution
0.1 V
Accuracy
± 0.25% F.S.
Current DC (Requires Option D)
Range
See model table in section 4.1 or 4.2
Resolution
0.01 A
Accuracy
± 0.5% F.S.
Note 1: AC Voltage measurement accuracy shown for Line to Neutral measurements. Line to Line voltage measurements
are calculated based on VLN and phase angles and are < 0.5% F.S. and valid only for sinusoidal voltage
waveforms with low levels of distortion and under balanced three phase load conditions.
Note 2: Measurement Accuracies for Current and Power apply for load currents of 2.0 A or more.
Note 3: For Power level above 100 W
