ADF SERIES® OPERATION MANUAL
SECTION 5: UNPACKING AND INSTALLATION
Entire Contents Copyright 2018 by Pacific Power Source, Inc. (PPS) • All Rights Reserved • No reproduction without written authorization from PPS.
ADF Series Power Source Operation Manual Page 45 of 349
Figure 5-4: AC Input Terminal Block - Rear Panel
5.5 Grounding Requirements
5.5.1 Chassis Ground Connection Required
SHOCK HAZARD: Equipment must be grounded.
RISQUE DE CHOC: l´équipement doit être mis à la terre.
The unit MUST be grounded via the AC Input. A line cord with proper Earth Ground must be
used at all times. Correct grounding of your electrical system infrastructure according to
applicable national standards must also be observed.
