Panasonic DMR-E55PL - Cabinet Parts List; Electrical Parts List

Ref.
No.
Part No. Part Name & Description Remarks
CABINET AND CHASSIS
REP3713A PANEL PCB [M]
(RTL)
ETXMM506M4F POWER PCB [M]
(RTL)
REP3662B MAIN PCB [M]
(RTL)
REP3717D DIGITAL PCB [M]
(RTL)
4 L6FAKCCE0002 DC FAN MOTOR [M]
5 RGR0347B-C1 REAR PANEL [M]
6 RKA0166-T LEG RUBBER [M]
7 XTBS3+8JFZ1 SCREW [M]
8 XSN3+4FZ SCREW [M]
9 RHDX30005 SCREW [M]
10 RHD30115-2 SCREW [M]
11 RMX0298 LOCKING CARD SPACER [M]
12 RYP1260-S FRONT PANEL UNIT [M]
12-1 RKF0690-K1 TRAY DOOR [M]
12-10 RGL0658-Q PANEL LIGHT [M]
12-11 RKF0689A-S PANEL DOOR [M]
12-12 RGK1776-Q FL ORNAMENT [M]
Ref.
No.
Part No. Part Name & Description Remarks
INTEGRATED CIRCUITS
IC1 STRG6353 IC SWITCHING [SPC]
IC101 TL431AILPR IC SWITCHING [SPC]
IC102 LM2904DR IC REGULATOR [SPC]
IC103 SI3010KM IC REG.+5V [SPC]
IC106 SI3120J IC REG.+5V [SPC]
IC1502 C0DBAHG00013 IC REG.JC+5V [M]
IC1505 C0CBCDD00008 IC REG.XSW+5.2V [M]
IC1506 C0CBCDD00002 IC REG.ANA+5V [M]
IC1507 C0CBCDD00006 IC REG.D+5V [M]
IC1508 C0DBEGD00002 IC REG.ANA+3.3V [M]
IC1509 C0DBEFG00003 IC REG.D+1.2V [M]
IC1510 C0DBEGG00003 IC REG.D+1.5V [M]
IC3001 C1AB00001918 IC VIDEO PROCESSOR [M]
IC3401 AN13310B-VB IC VAD CONTROLLER [M]
IC3402 C3ABRG000036 IC 16BIT/256M SDRAM [M]
IC3404 MN85573 IC AV ENC/RTSC [M]
IC3406 C1DB00001110 IC CLOCK GENERATOR [M]
IC3408 C3ABPJ000017 IC 32BIT/64M SDRAM [M]
IC3409 C0DBZGC00066 IC REG.D+3.3V [M]
IC4001 C1AB00001920 IC AUDIO SOUND PROCESSOR [M]
IC4004 C0CBCDC00026 IC REG.AU+5V [M]
IC4005 C0CBCDC00027 IC REG.AU+9V [M]
IC4402 C0FBBK000035 IC AUDIO 2CH D/A CONVERTER [M]
IC4403 C0JBAD000107 IC XD MUTE OUT [M]
IC4404 C0CBCBD00002 IC REG.DAC+3.3V [M]
IC4406 C0FBAK000008 IC AUDIO A/D CONVERTER [M]
IC6001 MN2DS0011-H IC AVDEC/MAIN CPU [M]
IC6002 C0EBE0000130 IC RESET [M]
IC6003 C3CBLD000088 IC 8MBIT LOADER [M]
IC6004 C0JBAZ001466 IC 8BIT BUFFER/DRIVER [M]
IC6005 C3ABQG000068 IC 16BIT/128M SDRAM [M]
IC6701 C1ZBZ0002429 IC GLUE [M]
IC6702 REP3717D DIGITAL P.C.B [M]
IC7404 C0BBBB000006 IC JC CLK OUT [M]
IC7501 C2CBJG000381 IC TIMER [M]
IC7502 C0HBB0000033 IC DISPLAY DRIVE [M]
IC7503 C0EBJ0000110 IC RESET [M]
IC7505 C0EBE0000194 IC SYS PFAIL (L) OUT [M]
IC7506 C0ABBA000146 IC FAN MOTOR DRIVE [M]
IC50001 C3ABPG000068 IC 16BIT/64M SDRAM [M]
IC50002 C3ABPG000068 IC 16BIT/64M SDRAM [M]
Ref.
No.
Part No. Part Name & Description Remarks
12-13 VGB0560 PANASONIC BADGE [M]
12-14 RHD26016 SCREW [M]
12-2 RGK1777-Q TRAY ORNAMENT [M]
12-3 VMB3410 BLINDER SPRING [M]
12-4 RGU2290A-S OPERATION BUTTON [M]
12-5 RGU2289-S POWER BUTTON [M]
12-6 RGU2291A-Q REC BUTTON [M]
12-7 RGK1774-S FRONT ORNAMENT L [M]
12-8 RGK1775-S FRONT ORNAMENT R [M]
12-9 RGK1773-S REC BUTTON RING [M]
14 RMC0595 EARTH PLATE [M]
15 RMA1778 FRONT ANGLE [M]
16 XTV26+10G SCREW (ORNAMENT) [M]
17 RHD30113 SCREW(SIDE) [M]
18 RKM0508-S TOP CABINET [M]
20 VXY1855 RAM DRIVE UNIT [M]
(RTL)
compati
ble
with
VXY1794
23 VWJ1731 DIGITAL-RAM DRIVE FF [M]
Ref.
No.
Part No. Part Name & Description Remarks
IR7801 B3RAD0000071 INFRARED RAYS [M]
TRANSISTORS
Q101 2SD602A-R TRANSISTOR [SPC]
Q102 2SB710AQRSTX TRANSISTOR [SPC]
Q103 2SB0709ARL TRANSISTOR [SPC]
Q104 2SD601A-R TRANSISTOR [SPC]
Q105 2SK3366 TRANSISTOR [SPC]
Q106 2SD601A-R TRANSISTOR [SPC]
Q107 2SD601A-R TRANSISTOR [SPC]
Q110 2SB710AQRSTX TRANSISTOR [SPC]
Q111 2SD601A-R TRANSISTOR [SPC]
Q113 2SK3366 TRANSISTOR [SPC]
Q114 2SB710AQRSTX TRANSISTOR [SPC]
Q115 2SD601A-R TRANSISTOR [SPC]
Q116 2SD601A-R TRANSISTOR [SPC]
Q117 2SB0709ARL TRANSISTOR [SPC]
Q118 2SD602A-R TRANSISTOR [SPC]
Q119 2SB710AQRSTX TRANSISTOR [SPC]
Q4001 2SB1218A0L TRANSISTOR [M]
Q4002 2SD132800L TRANSISTOR [M]
Q4003 2SD132800L TRANSISTOR [M]
Q6001 B1ABCF000114 TRANSISTOR [M]
Q6002 B1ABCF000114 TRANSISTOR [M]
Q6701 B1ABCF000114 TRANSISTOR [M]
Q6702 B1ABCF000114 TRANSISTOR [M]
Q6703 B1ABCF000114 TRANSISTOR [M]
Q6704 B1ABCF000114 TRANSISTOR [M]
Q6705 B1ABCF000114 TRANSISTOR [M]
Q7401 2SB1218A0L TRANSISTOR [M]
Q7503 2SD1994BR1VT TRANSISTOR [M]
Q7504 2SD0601A0L TRANSISTOR [M]
Q7507 2SB0709A0L TRANSISTOR [M]
Q7508 2SD1819A0L TRANSISTOR [M]
Q7512 2SD0874A0L TRANSISTOR [M]
Q50001 B1ADCF000081 TRANSISTOR [M]
Q50002 B1ADCF000081 TRANSISTOR [M]
Q50003 B1ADCF000081 TRANSISTOR [M]
Q50004 B1ADCF000081 TRANSISTOR [M]
Q50005 B1ADCF000081 TRANSISTOR [M]
QR3401 UNR521L00L TRANSISTOR [M]
QR4001 UNR521100L CHIP TRANSISTOR [M]
24.1. Cabinet Parts List
24.2. Electrical Parts List
105
DMR-E55PL
