Panasonic DMR-E55PL - P9001 Waveform; Display

16.5. P9001 Waveform
T1150-3 STOP
29Vp-p (5 sec.div)
T1150-4 STOP
330Vp-p (5
sec.div)
T1150-6 STOP
11Vp-p (5m sec.div)
T1150-8 STOP
15Vp-p (5
sec.div)
T1150-9,10 STOP
15Vp-p (5
sec.div)
IC1150-1 STOP
8.0Vp-p (5
sec.div)
IC1150-2 STOP
1.9Vp-p (5 sec.div)
P7402-2 REC/PLAY
0.8Vp-p (20
sec.div)
P7402-30 REC/PLAY
0.5Vp-p (20
sec.div)
P7402-26 REC/PLAY
0.8Vp-p (20
sec.div)
P7402-18 REC/PLAY
0.7Vp-p (20
sec.div)
P7402-22 REC/PLAY
0.8Vp-p (20
sec.div)
P7402-48,50 REC/PLAY
1.6Vp-p (1m sec.div)
P7402-34 REC/PLAY
0.5Vp-p (20
sec.div)
JK3903-19 REC/PLAY
1.0Vp-p (20
sec.div)
JK3903-18 REC/PLAY
1.0Vp-p (20
sec.div)
JK3903-20 REC/PLAY
1.5Vp-p (20
sec.div)
