Panasonic DMR-E55PL - Display

Ref.
No.
Part No. Part Name & Description Remarks
COILS & TRANSFORMERS
L2 ELF15N005A COIL [SPC]
L4 ELESN150KA COIL [SPC]
L5 EXCELSR35 COIL [SPC]
L10 EXCELSA35 COIL [SPC]
L11 EXCELSA35 COIL [SPC]
L101 EXCELDR35 COIL [SPC]
L102 LHLZ1R5M COIL [SPC]
L103 EXCELDR35 COIL [SPC]
L104 LHLZ6R8M COIL [SPC]
L105 EXCELSA35 COIL [SPC]
L107 EXCELSA35 COIL [SPC]
L108 EXCELDR35 COIL [SPC]
L109 LHLZ4R7M COIL [SPC]
L1501 G0A220G00018 INDUCTOR [M]
L3001 ELEXT220JBV FIXED INDUCTORS [M]
L3002 ELEXT220JBV FIXED INDUCTORS [M]
L4901 ELESN220KA INDUCTOR [M]
L7401 G0A220G00018 INDUCTOR [M]
L7502 ELESN101KA CHOKE COIL [M]
T1 ETB28BF1U6A TRANSFORMER [M]
T7501 ETS13TB119AP TRANSFORMER [M]
B7501 CR2354-1GUF LITHIUM BATTERY [M]
TU7401 ENGD6201D TV TUNER PACK [M]
OSCILLATORS
X3401 H0J270500069 FIELD MOUNTING CRY. [M]
X7501 H0D100500016 CRYSTAL RESONATORS [M]
X7502 H0A327200026 CRYSTAL OSCILLATOR [M]
DISPLAY TUBE
FL3401 F1H0J4740004 0.47 6.3V [M]
FL3402 F1H0J4740004 0.47 6.3V [M]
FL3404 F1H0J4740004 0.47 6.3V [M]
FL3406 F1H0J4740004 0.47 6.3V [M]
FL3407 F1H0J4740004 0.47 6.3V [M]
FL3409 F1H0J4740004 0.47 6.3V [M]
FL3410 F1H0J4740004 0.47 6.3V [M]
FL3411 F1H0J4740004 0.47 6.3V [M]
FL3412 F1H0J4740004 0.47 6.3V [M]
FL3414 F1H0J4740004 0.47 6.3V [M]
FL3415 F1H0J4740004 0.47 6.3V [M]
FL3416 F1H0J4740004 0.47 6.3V [M]
FL3417 F1H0J4740004 0.47 6.3V [M]
FL3418 F1H0J4740004 0.47 6.3V [M]
FL3419 F1H0J4740004 0.47 6.3V [M]
FL3420 F1H0J4740004 0.47 6.3V [M]
FL3421 F1H0J4740004 0.47 6.3V [M]
FL3422 F1H0J4740004 0.47 6.3V [M]
FL3423 F1H0J4740004 0.47 6.3V [M]
FL3424 F1H0J4740004 0.47 6.3V [M]
FL3425 F1H0J4740004 0.47 6.3V [M]
FL3426 F1H0J4740004 0.47 6.3V [M]
FL3429 F1H0J4740004 0.47 6.3V [M]
FL3431 F1H0J4740004 0.47 6.3V [M]
FL3433 F1H0J4740004 0.47 6.3V [M]
FL3434 F1H0J4740004 0.47 6.3V [M]
FL3435 F1H0J4740004 0.47 6.3V [M]
FL4401 F1H0J4740004 0.47 6.3V [M]
FL4402 F1H0J4740004 0.47 6.3V [M]
FL6001 F1H0J4740004 0.47 6.3V [M]
FL6002 F1H0J4740004 0.47 6.3V [M]
FL6003 F1H0J4740004 0.47 6.3V [M]
FL6004 F1H0J4740004 0.47 6.3V [M]
FL6005 F1H0J4740004 0.47 6.3V [M]
FL6006 F1H0J4740004 0.47 6.3V [M]
Ref.
No.
Part No. Part Name & Description Remarks
FL6008 F1H0J4740004 0.47 6.3V [M]
FL6009 F1H0J4740004 0.47 6.3V [M]
FL6010 F1H0J4740004 0.47 6.3V [M]
FL6011 F1H0J4740004 0.47 6.3V [M]
FL6012 F1H0J4740004 0.47 6.3V [M]
FL6013 F1H0J4740004 0.47 6.3V [M]
FL6014 F1H0J4740004 0.47 6.3V [M]
FL6015 F1H0J4740004 0.47 6.3V [M]
FL6016 F1H0J4740004 0.47 6.3V [M]
FL6017 F1H0J4740004 0.47 6.3V [M]
FL6020 F1H0J4740004 0.47 6.3V [M]
FL6021 F1H0J4740004 0.47 6.3V [M]
FL6022 F1H0J4740004 0.47 6.3V [M]
FL6023 F1H0J4740004 0.47 6.3V [M]
FL6701 F1H0J4740004 0.47 6.3V [M]
FL6702 F1H0J4740004 0.47 6.3V [M]
FL6703 F1H0J4740004 0.47 6.3V [M]
FL50001 F1H0J4740004 0.47 6.3V [M]
FL50002 F1H0J4740004 0.47 6.3V [M]
FL50003 F1H0J4740004 0.47 6.3V [M]
FL50004 F1H0J4740004 0.47 6.3V [M]
FL50005 F1H0J4740004 0.47 6.3V [M]
FL50006 F1H0J4740004 0.47 6.3V [M]
FUSES
F1 19181-2A FUSE [SPC]
F101 SBM40 FUSE [SPC]
F102 SBM32 FUSE [SPC]
F103 SBM25 FUSE [SPC]
F1101 K5D162BK0005 FUSE [M]
COMBINATIONS
PC1 PS2571L1 PHOTO COUPLER [SPC]
VR101 ER0S2TKF1580 0.25W 158 [SPC]
Z1 ERZVGAD471 VARISTOR [SPC]
FUSE PROTECTOR
IP101 ICPN10 IC PROTECTOR [SPC]
IP7501 D4FAR4000001 FUSIBLE RESISTOR [M]
EARTH TERMINALS
ZJ7407 K9ZZ00000424 TERMINAL [M]
ZJ7408 K9ZZ00000424 TERMINAL [M]
DP7501 A2BD00000074 FL CHARACTER DISPLAY [M]
JACKS
JK3901 K1U822B00003 JK MULTI. CONNECTOR [M]
JK3902 K1U412B00001 JK MULTI. CONNECTOR [M]
JK3903 K1U407B00002 JK MAIN PCB [M]
JK3904 K1U415B00001 JK MULTI. CONNECTOR [M]
P1 M2023 AC INLET [SPC]
CHIP JUMPERS
W601 ERJ3GEY0R00V 0 1/16W [M]
W602 ERJ3GEY0R00V 0 1/16W [M]
W603 ERJ3GEY0R00V 0 1/16W [M]
W604 ERJ6GEY0R00V 0 1/10W [M]
W605 ERJ6GEY0R00V 0 1/10W [M]
W606 ERJ3GEY0R00V 0 1/16W [M]
W607 ERJ3GEY0R00V 0 1/16W [M]
107
DMR-E55PL
