Panasonic DMR-E55PL - Display

Ref.
No.
Part No. Part Name & Description Remarks
W608 ERJ3GEY0R00V 0 1/16W [M]
W609 ERJ3GEY0R00V 0 1/16W [M]
W610 ERJ3GEY0R00V 0 1/16W [M]
W611 ERJ6GEY0R00V 0 1/10W [M]
W612 ERJ3GEY0R00V 0 1/16W [M]
W613 ERJ3GEY0R00V 0 1/16W [M]
W614 ERJ3GEY0R00V 0 1/16W [M]
W615 ERJ3GEY0R00V 0 1/16W [M]
W616 ERJ3GEY0R00V 0 1/16W [M]
W617 ERJ3GEY0R00V 0 1/16W [M]
W618 ERJ3GEY0R00V 0 1/16W [M]
W622 ERJ3GEY0R00V 0 1/16W [M]
W623 ERJ3GEY0R00V 0 1/16W [M]
W624 ERJ3GEY0R00V 0 1/16W [M]
RESISTORS
R1 ERDS1FJ105 0.5W 1M [SPC]
R2 CR10J681 0.1W 680 [SPC]
R3 ERX1SZGR47 1W 0.47 [SPC]
R5 ERDS2FJ224 1/4W 220K [SPC]
R6 ER0S2TKF2373 0.25W 237K [SPC]
R7 CR10F1272 0.1W 12.7K [SPC]
R8 CR10J562 0.1W 5.6K [SPC]
R9 ERDS2FJ224 1/4W 220K [SPC]
R10 ER0S2TKF2373 0.25W 237K [SPC]
R101 CR10J472 0.1W 4.7K [SPC]
R102 CR10J100 0.1W 10 [SPC]
R103 CR10J100 0.1W 10 [SPC]
R104 CR10J471 0.1W 470 [SPC]
R105 CR10J472 0.1W 4.7K [SPC]
R106 ERJ6GEYJ101V 1/8W 100 [SPC]
R107 CR10J224 0.1W 220K [SPC]
R108 CR10J472 0.1W 4.7K [SPC]
R109 CR10J222 0.1W 2.2K [SPC]
R110 CR10J103 0.1W 10K [SPC]
R111 CR10J752 0.1W 7.5K [SPC]
R112 CR10J102 0.1W 1K [SPC]
R113 CR10J471 0.1W 470 [SPC]
R114 ERDS2FJ101 1/4W 100 [SPC]
R115 CR10J332 0.1W 3.3K [SPC]
R116 CR10J102 0.1W 1K [SPC]
R117 ERJ6GEYJ101V 1/8W 100 [SPC]
R120 CR10F2210 0.1W 221 [SPC]
R121 CR10F1001 0.1W 1K [SPC]
R122 CR10J183 0.1W 18K [SPC]
R124 CR10F1470 0.1W 147 [SPC]
R125 CR10J103 0.1W 10K [SPC]
R126 CR10F1002 0.1W 10K [SPC]
R127 CR10F3321 0.1W 3.32K [SPC]
R128 CR10F1211 0.1W 1.21K [SPC]
R130 CR10J822 0.1W 8.2K [SPC]
R131 CR10J103 0.1W 10K [SPC]
R132 CR10J472 0.1W 4.7K [SPC]
R136 CR10J152 0.1W 1.5K [SPC]
R137 CR10J152 0.1W 1.5K [SPC]
R139 CR10J123 0.1W 12K [SPC]
R143 ERDS2FJ822 1/4W 8.2K [SPC]
R144 CR10J222 0.1W 2.2K [SPC]
R145 CR10F6810 0.1W 681 [SPC]
R153 CR10F1002 0.1W 10K [SPC]
R154 CR10F3321 0.1W 3.32K [SPC]
R157 CR10F2210 0.1W 221 [SPC]
R158 CR10J682 0.1W 6.8K [SPC]
R159 CR10J103 0.1W 10K [SPC]
R160 CR10J332 0.1W 3.3K [SPC]
R163 CR10J183 0.1W 18K [SPC]
R164 CR10J222 0.1W 2.2K [SPC]
R165 CR10J103 0.1W 10K [SPC]
R166 CR10J103 0.1W 10K [SPC]
R167 CR10J152 0.1W 1.5K [SPC]
R168 CR10J152 0.1W 1.5K [SPC]
R169 CR10J102 0.1W 1K [SPC]
Ref.
No.
Part No. Part Name & Description Remarks
R170 CR10J752 0.1W 7.5K [SPC]
R171 CR10J472 0.1W 4.7K [SPC]
R172 ERJ6GEYJ101V 1/8W 100 [SPC]
R173 CR10J224 0.1W 220K [SPC]
R174 CR10J471 0.1W 470 [SPC]
R175 CR10J472 0.1W 4.7K [SPC]
R176 CR10F1002 0.1W 10K [SPC]
R177 CR10F2432 0.1W 24.3K [SPC]
R178 CR10J472 0.1W 4.7K [SPC]
R179 CR10J223 0.1W 22K [SPC]
R1501 ERJ3GEYJ822V 8.2K 1/16W [M]
R1502 D0GB332JA002 3.3K 1/16W [M]
R1503 D0GB101JA002 100 1/16W [M]
R1504 ERDS2TJ271T 270 1/4W [M]
R1506 ERDS2TJ271T 270 1/4W [M]
R1507 ERJ3RED330V 33 3W [M]
R1508 ERJ3RBD201V 200 3W [M]
R1509 ERJ3RBD102V 1K 3W [M]
R1510 ERJ3RED220V 22 3W [M]
R1511 ERJ3RBD182V 1.8K 3W [M]
R1512 ERJ3RBD202V 2K 3W [M]
R1515 ERDS2TJ271T 270 1/4W [M]
R1516 ERDS2TJ271T 270 1/4W [M]
R3025 ERJ3RBD153V 15K 3W [M]
R3026 D0GB105JA002 1M 1/16W [M]
R3027 ERJ3GEY0R00V 0 1/16W [M]
R3028 ERJ3GEYJ471V 470 1/16W [M]
R3029 ERJ3GEY0R00V 0 1/16W [M]
R3030 D0GB750JA019 75 1/16W [M]
R3031 ERJ3GEY0R00V 0 1/16W [M]
R3032 ERJ3GEYJ103V 10K 1/16W [M]
R3033 ERJ3GEYJ103V 10K 1/16W [M]
R3036 ERJ3GEYJ103V 10K 1/16W [M]
R3038 ERJ3GEYJ330V 33 1/16W [M]
R3039 ERJ3GEYJ221V 220 1/16W [M]
R3040 ERJ3GEYJ221V 220 1/16W [M]
R3041 ERJ3RBD104V 100K 3W [M]
R3405 ERJ2GEJ103X 10K 2W [M]
R3407 ERJ2GE0R00X 02W [M]
R3409 ERJ2GE0R00X 02W [M]
R3410 ERJ2GEJ101X 100 2W [M]
R3411 ERJ2GEJ101X 100 2W [M]
R3412 ERJ2GEJ220X 22 2W [M]
R3414 ERJ2GEJ330X 33 2W [M]
R3416 ERJ2GEJ472X 4.7K 2W [M]
R3417 ERJ2GEJ103X 10K 2W [M]
R3418 ERJ2GEJ103X 10K 2W [M]
R3419 ERJ2GEJ220X 22 2W [M]
R3420 ERJ2GEJ220X 22 2W [M]
R3421 ERJ2GEJ220X 22 2W [M]
R3422 ERJ2GEJ220X 22 2W [M]
R3423 ERJ2GEJ220X 22 2W [M]
R3427 ERJ2GEJ220X 22 2W [M]
R3430 ERJ2GEJ220X 22 2W [M]
R3440 ERJ2GEJ103X 10K 2W [M]
R3442 ERJ2GEJ103X 10K 2W [M]
R3443 ERJ2GE0R00X 02W [M]
R3444 ERJ2GE0R00X 02W [M]
R3445 ERJ2GE0R00X 02W [M]
R3447 ERJ2RHD682X 6.8K 2W [M]
R3448 ERJ2GEJ562X 5.6K 2W [M]
R3449 ERJ2RHD682X 6.8K 2W [M]
R3450 ERJ2GEJ104X 100K 2W [M]
R3451 ERJ2GEJ220X 22 2W [M]
R3452 ERJ2GE0R00X 02W [M]
R3453 ERJ2GEJ220X 22 2W [M]
R3454 ERJ2GEJ390X 39 2W [M]
R3455 ERJ2GEJ220X 22 2W [M]
R3456 ERJ2GEJ220X 22 2W [M]
R3457 ERJ2GE0R00X 02W [M]
R3460 ERJ2GEJ470X 47 2W [M]
R3461 ERJ2GEJ470X 47 2W [M]
R3462 ERJ2GEJ470X 47 2W [M]
