FP3 MEWNET-TR
Chapter8-2. Page.123
119
3. Expansion FP I/O Terminal Unit
J
8-input type (AFP87425) and 8-output type (AFP87427)
(unit : mm/in.)
60.0/2.362
35
1.0/1.378
0.039
110.0/4.331
45.0/1.772
6.5/0.256
J
16-input type (AFP87426) and 16-output type (AFP87428)
(unit : mm/in.)
60.0/2.362
35
1.0/1.378
0.039
180.0/7.087
45.0/1.772
6.5/0.256
8-2. Dimensions
