Panasonic KX-TDA30

2.8 Connection of DECT Portable Stations — KX-TDA100/KX-TDA200
162 Installation Manual
2.8.8 Wall Mounting
1. Place the reference for wall mounting (on the following page) on the wall to mark the 2
screw positions.
2. Install the 2 screws and washers (included) into the wall.
Notes
• Make sure that the screw heads are at the same distance from the wall.
• Install the screws perpendicular to the wall.
3. Hook the CS on the screw heads.
