2.2 Installation of the Hybrid IP-PBX — KX-TDA100/KX-TDA200
48 Installation Manual
2.2.7 Installing/Removing the Optional Service Cards
Slot Condition
CAUTION
To protect the back board from static electricity, do not touch parts on the back board in
the main unit and on the optional service cards. To discharge static electricity, touch
ground or wear an earthing strap.
Note
The optional service cards can be installed or removed while the DC power is supplied.
However, when installing or removing the MPR card, the DC power supply must be turned
off.
Installing Optional Service Cards
1. Insert the card along the guide rails.
Card Type Slot Type
KX-TDA100: Free Slots 1 to 5
KX-TDA200: Free Slots 1 to 10
Option Slot MPR Slot
MPR Card No No Yes
Trunk Cards Yes No No
Extension Cards Yes No No
OPB3 Card Yes Yes No
CTI-LINK Card Yes Yes No
Guide Rail
