2.9 Connection of 2.4 GHz Portable Stations — KX-TDA100/KX-TDA200
164 Installation Manual
2.9 Connection of 2.4 GHz Portable Stations —
KX-TDA100/KX-TDA200
2.9.1 Overview
The following equipment is required to connect the wireless system:
CS: Cell Station (KX-TDA0142/KX-TDA0141)
KX-TDA0142 Using a CSIF Card
This unit determines the area covered by the wireless system. Up to 3 calls can be made
at the same time through each CS.
• CSIF4 (KX-TDA0143)
One CSIF4 card supports up to 4 Cell Stations. Up to 2 CSIF4 cards can be
connected to the KX-TDA100, and up to 4 can be connected to the KX-TDA200.
• CSIF8 (KX-TDA0144)
One CSIF8 card supports up to 8 Cell Stations. Up to 2 CSIF8 cards can be
connected to the KX-TDA100, and up to 4 can be connected to the KX-TDA200.
KX-TDA0141 Using a DHLC/DLC Card
This unit determines the area covered by the wireless system. Up to 2 calls can be made
at the same time through each CS.
PS: 2.4 GHz Portable Station (KX-TD7680/KX-TD7690)
The KX-TDA100 and KX-TDA200 can support up to 128 PSs. For more details about the PS,
refer to the PS Operating Instructions.
CAUTION
• The CS should be kept free of dust, moisture, high temperature (more than 40 °C),
low temperature (less than 0 °C), vibration, and should not be exposed to direct
sunlight.
• The CS should not be placed outdoors (use indoors).
• The CS should not be placed near high voltage equipment.
• The CS should not be placed on a metal object.
• Systems using 2.4 GHz ISM (Industrial, Scientific and Medical) band may interfere
with the KX-TDA wireless system. Examples of such systems are cordless
telephones, wireless LAN, Home RF, microwave ovens and other ISM devices. These
systems may cause minor noise.
• Keeping some distance between the equipment listed below may prevent
interference. (The distance may vary depending on the environment.)
Equipment Distance
CS and office equipment such as a computer, telex,
fax machine, etc.
More than 2 m
CS and PS More than 1 m
Each PS More than 0.5 m
Hybrid IP-PBX and CS More than 2 m
