2.2 Installation of the Hybrid IP-PBX — KX-TDA100/KX-TDA200
Installation Manual 59
2.2.11 Wall Mounting (KX-TDA200)
CAUTION
Drive mounting screws into the wall. Be careful to avoid touching any metal laths, wire
laths or metal plates in the wall.
1. Install 4 anchor plugs in the wall, using the metal bracket as a template. Fix the metal
bracket with 4 screws (A).
Screw (A)
Screw (A)
Metal Bracket
Hammer
Anchor Plug
30 mm
6.5 mm
Wall
TOP
TOP
Anchor Plug
Metal Bracket
